Meet the Instrument Turntable Model IT-10R, Rev-B – a cutting-edge solution designed for precision and reliability in gas company meter shops. This advanced instrument is engineered to calibrate and check the performance of mechanical volume recorders and electronic volume correctors with unparalleled accuracy.
Key Features
Versatile Compatibility
The turntable's instrument drive and multi-meter bolt pattern are compatible with most volume recorders and volume correctors.
Accurate Measurements
The integral digital counter displays pseudo meter rotations, ensuring precise calibration every time.
Bi-Directional Motor
Powered by an AC motor with adjustable rotation direction (CW – Off – CCW), allowing flexible operation.
Remote Monitoring
An integral Form-A switch closure enables remote counting of meter rotations.
Durable Design
Constructed with a robust 1/4” aluminum base plate, painted blue for a sleek finish.
User-Friendly
Features a 6-digit, 7-segment LCD digital counter with a reset button for easy operation.
Turntable
-
Motor Speed: Fixed at 10 RPM
-
Motor Input Power: 100 - 240 VAC, 47 - 63 Hz
-
Fuse Rating: 1 Amp
-
Environmental Use: Indoor only
-
Pulse Output: Dry contact switch, max 100 VDC, 500 mA
-
Dimensions: 12” L x 12” W x 3” H
-
Weight: 3.5 lbs
Enhance the accuracy and efficiency of your meter calibration processes with the Instrument Turntable Model IT-10R, Rev-B.
-
